100W RF Attenuator with Insulation Material-Ptfe Frequency Range 600-5925MHz 600-5925MHz
- Overview
- FAQ
- Recommended Products
- High Power Capacity & Broad Bandwidth Supports 100W power; covers 600-5925MHz (VSWR ≤1.3 optimized for 600-3800MHz) for multi-band RF systems.
- Precise Attenuation & Low Distortion 3-20dB attenuation options (tolerances ±1.2~2.0dB); ultra-low intermodulation (≤-160dBc @ 2×43dBm) and VSWR (≤1.35) ensure clean signal output.
- Durable PTFE Insulation & IP65 Protection PTFE insulation material + IP65-rated enclosure; operates in -20°C~+60°C (storage: -40°C~+85°C) for harsh indoor/outdoor environments.
- Universal 50Ω Impedance Standard 50Ω impedance for seamless integration with most RF test/communication equipment.
- High-Power Wireless Networks (5G macro base stations, LTE transmitters) for signal power adjustment.
- RF Test Labs & Field Testing to safeguard sensitive instruments from 100W-level high-power signals.
- Outdoor Telecom Infrastructure (tower-mounted equipment, outdoor transmitters) via IP65 waterproofing.
- Satellite & Broadband Systems (600-5925MHz range) for stable signal regulation in extreme conditions.
Frequency band |
600-5925MHz |
||||||||||||||||
Attenuation(dB) |
3 |
5 |
6 |
7 |
8 |
10 |
13 |
15 |
20 |
||||||||
+1.5 |
±1.5 |
±1.5 |
±1.5 |
±1.5 |
±1.5 |
±1.5 |
±2.0 |
±2.0 |
|||||||||
VSWR |
≤1.35 |
||||||||||||||||
Frequency band |
600-3800MHz |
||||||||||||||||
Attenuation(dB) |
3 |
5 |
6 |
7 |
8 |
10 |
13 |
15 |
20 |
||||||||
+1.2 |
±1.2 |
±1.2 |
±1.2 |
±1.5 |
±1.5 |
±1.5 |
±2.0 |
±2.0 |
|||||||||
VSWR |
≤1.3 |
||||||||||||||||
Power Rating |
100 W |
||||||||||||||||
Intermodulation (dBc) |
≤-160dBc (with 2×43dBm) |
||||||||||||||||
Impedance (Ω) |
50 |
||||||||||||||||
Temperature range |
-20 °C to +60 °C |
||||||||||||||||
Storage temperature |
-40 °C to +85 °C |
||||||||||||||||
Relative humidity |
5% - 95% |
||||||||||||||||
Application |
(IP65) |
||||||||||||||||
FAQ
Q:what's your company MOQ?
A: In generally, if use customer brand, we will ask at least 500~800pcs, this we can negotiate.
Q: What's your delivery time?
A: This please ask our stock in first, products can send out once receive your deposit. If use customer brands, we will take a 3-5days to prepare materials and mass production.
Q: Can your company accept customize?
A: Welcome OEM & ODM.
Q: Can you send a sample for us to develop?
A: Yes, we can. Sample can send out once you ask for it, but will ask a sample fee. Sample fee will return back in future order
Q: Can you guarantee the quality of product?
A: Sure, high quality give us confidence to do business with your company. Long-term cooperation is what we need most instead of short-term cooperation.
Q: How do you solve after sale service?
A: This please ask us for technical support if you have workers know how to repair. If do not have engineers, please send back the items, we can repair the items for you.
Q:How do your company deal with the problem on quality ?
A: We have 20 years experience in this business. High quality and perfect service earn us great reputation. We will have a
detailed analysis of the problem. If our product is unqualified, we will deal with the problem according to contract. You have no need to worry about following problem. Our team will provide you great service.
