20-50W RF Attenuator with Insulation Material 600-5925MHz 20-50W RF Attenuator
- Overview
- FAQ
- Recommended Products
- Broad Frequency Coverage Covers 600-5925MHz (optimized VSWR ≤1.3 for 600-3800MHz), compatible with multi-band RF systems.
- High Power & Stable Attenuation Supports 20-50W power; offers 3-20dB attenuation options with tight tolerances (±1.2~2.0dB).
- Low Intermodulation & VSWR Ultra-low intermodulation (≤-160dBc @ 2×43dBm) and low VSWR (≤1.35), ensuring minimal signal distortion.
- Rugged & Weatherproof Design IP65-rated enclosure with insulation material; operates in -20°C~+60°C (storage: -40°C~+85°C), suitable for harsh environments.
- Standard 50Ω Impedance Universal 50Ω impedance for seamless integration with most RF equipment.
- Wireless Communication Systems (e.g., 5G, LTE, Wi-Fi base stations) for signal power adjustment.
- RF Test & Measurement Setups (lab/field testing) to protect sensitive test instruments from high-power signals.
- Outdoor RF Infrastructure (telecom towers, outdoor transmitters) thanks to IP65 waterproofing.
- Satellite Communication Equipment for frequency band signal regulation in 600-5925MHz range.
Frequency band |
600-5925MHz |
||||||||||||||||
Attenuation(dB) |
3 |
5 |
6 |
7 |
8 |
10 |
13 |
15 |
20 |
||||||||
+1.5 |
±1.5 |
±1.5 |
±1.5 |
±1.5 |
±1.5 |
±1.5 |
±2.0 |
±2.0 |
|||||||||
VSWR |
≤1.35 |
||||||||||||||||
Frequency band |
600-3800MHz |
||||||||||||||||
Attenuation(dB) |
3 |
5 |
6 |
7 |
8 |
10 |
13 |
15 |
20 |
||||||||
+1.2 |
±1.2 |
±1.2 |
±1.2 |
±1.5 |
±1.5 |
±1.5 |
±2.0 |
±2.0 |
|||||||||
VSWR |
≤1.3 |
||||||||||||||||
Power Rating |
20-50 W |
||||||||||||||||
Intermodulation (dBc) |
≤-160dBc (with 2×43dBm) |
||||||||||||||||
Impedance (Ω) |
50 |
||||||||||||||||
Temperature range |
-20 °C to +60 °C |
||||||||||||||||
Storage temperature |
-40 °C to +85 °C |
||||||||||||||||
Relative humidity |
5% - 95% |
||||||||||||||||
Application |
(IP65) |
||||||||||||||||
FAQ
Q:what's your company MOQ?
A: In generally, if use customer brand, we will ask at least 500~800pcs, this we can negotiate.
Q: What's your delivery time?
A: This please ask our stock in first, products can send out once receive your deposit. If use customer brands, we will take a 3-5days to prepare materials and mass production.
Q: Can your company accept customize?
A: Welcome OEM & ODM.
Q: Can you send a sample for us to develop?
A: Yes, we can. Sample can send out once you ask for it, but will ask a sample fee. Sample fee will return back in future order
Q: Can you guarantee the quality of product?
A: Sure, high quality give us confidence to do business with your company. Long-term cooperation is what we need most instead of short-term cooperation.
Q: How do you solve after sale service?
A: This please ask us for technical support if you have workers know how to repair. If do not have engineers, please send back the items, we can repair the items for you.
Q:How do your company deal with the problem on quality ?
A: We have 20 years experience in this business. High quality and perfect service earn us great reputation. We will have a
detailed analysis of the problem. If our product is unqualified, we will deal with the problem according to contract. You have no need to worry about following problem. Our team will provide you great service.
