Specifications
1.reasonable price
2.manufacturer factory
3.We are able to supply various types of connector according to clients’ requirement
4.Samples can be supplied for testing (for free)
5.Tried order is available
6.in stock
If you can not find the exact products you want in this page, please send enquiry to us, you will get an immediate reply within 1 hour at our working time, thanks for your visiting!~
Technical Characteristics
|
Temperature Range |
-55~+155°C (PE Cable -40~+85°C) |
|
|
Impedance |
50Ω |
|
|
Vibration |
98m/S2 (10~2000Hz), 10g |
|
|
Frequency Range |
DC-12.4GHz(semi-rigid cable DC-18 GHz) |
|
|
Insertion Loss |
<= 0.15dB/6GHz |
|
|
Withstanding Voltage |
1000V r.m.s at sea level |
|
|
Working Voltage |
335Vr.m.s at sea level |
|
|
Insulation Resistance |
>= 5000 MΩ |
|
|
Durability |
>= 500(cycles) |
|
|
Contact resistance: |
CenterContact <= 3mΩ |
|
|
Outer Contact <= 2.5mΩ |
||
|
Voltage Standing Wave Ratio: |
Straight |
flex cable <= 1.10+0.02f |
|
Semi-rigid cable <= 1.07+0.018f |
||
|
Right angle |
flex cable <= 1.20+0.03f |
|
|
Semi-rigid cable <= 1.17+0.02f |
||
