N Type Straight Female to RP-SMA Female(Pin) Connector Adapter N to RP-SMA Adapter
- Overview
- Recommended Products
N type straight female to RP-SMA female(Pin) connector adapter N to RP-SMA adapter
1.reasonable price
2.manufacturer factory
3.We are able to supply various types of connector according to clients’ requirement
4.Samples can be supplied for testing (for free)
5.Tried order is available
6.in stock
N type straight female to RP SMA female(Pin) connector adapter N to RP-SMA adapter
|
Key Performance |
||||
|
Temperature range |
-65~+165 |
Insulation resistance |
≥5000MΩ |
|
|
Characteristic impedance |
50Ω |
Dielectric Withstanding voltage |
1500V |
|
|
Frequency range |
0~11GHz |
Contact resistance |
Center conductor |
≤1mΩ |
|
Outer conductor |
≤0.2mΩ |
|||
|
VSWR |
≤1.30 |
Durability |
500 Cycles |
|
|
Material And Plating |
||||
|
Body |
Brass , gold/nickel plated |
|||
|
Male center contacts |
Brass , gold plated |
|||
|
Female center contacts |
Beryllium copper or phosphor bronze , gold plated |
|||
|
Insulators |
PTFE |
|||
|
Gaskets |
Silicone rubber |
|||
|
Crimp ferrules |
Copper alloy , nickel plated |
|||
