SMA to 4.3-10 Female Adapter Connector LOW PIM 4 HOLE FLANGE MOUNTING
50Ω RF Adapter Connector: SMA to 4.3-10 Female, 4-Hole Flange Mount, Low VSWR
- Overview
- FAQ
- Recommended Products
- Ultra-Low PIM Performance Delivers ≤-165dBc PIM at 2×20W, eliminating intermodulation interference for critical communication systems like 5G base stations.
- Broadband & Low-Loss Transmission Covers DC to 6GHz with VSWR ≤1.10 and insertion loss ≤0.05dB, ensuring minimal signal attenuation across high-frequency bands.
- Robust Flange Mounting 4-hole flange design provides secure, vibration-resistant installation in panels, enclosures, and equipment chassis.
- Durable & Corrosion-Resistant Tri-alloy plating on brass body and phosphor bronze center conductor withstands ≥500 mating cycles and 96 hours of salt-fog exposure.
- High Electrical Reliability PTFE insulator ensures ≥2500V RMS dielectric withstand voltage and ≥5000MΩ insulation resistance for stable performance.
- Full Environmental Compliance RoHS-compliant and operable from -40℃ to +85℃, suitable for harsh outdoor and industrial environments.
- Telecom Infrastructure Used in 5G/4G base station antenna systems to adapt SMA-based radios to 4.3-10 antenna feeds, ensuring low PIM and reliable signal transfer.
- Test & Measurement Ideal for lab setups, signal analyzers, and network testers, providing precise, repeatable connections between SMA test ports and 4.3-10 devices.
- Aerospace & Defense Applied in radar systems, satellite communication terminals, and airborne equipment, where vibration resistance and wide temperature tolerance are essential.
- Industrial IoT & Outdoor Networks Enables connection between SMA sensors/radio modules and 4.3-10 outdoor antennas in smart city, utility, and transportation networks.
- Wireless Infrastructure Used in distributed antenna systems (DAS) and small cell deployments to adapt between SMA and 4.3-10 components in confined spaces.
SMA to 4.3-10 Female adapter connector LOW PIM 4 HOLE FLANGE MOUNTING
| Electrical | |
| Characteristic Impedance | 50ohm |
| Frequency Range | DC-6GHz |
| VSWR | 1.10 |
| Dielectric withstanding voltage | ≥2500RMS,50Hz,at sea level |
| Dielectric Resistance | ≥5000MΩ |
| PIM ( @2-tonex20w) | ≤-165dBc |
| Insertion Loss | ≤0.05 |
| Mechanical | |
| Durability | Mating cycles ≥500 |
| Environmental | |
| Temperature Range | -40℃~+85℃ |
| Rosh-compliance | Full ROHS compliance |
| Salt-fog test | 96h |
| Material and plating | ||
| Description | Material | Plating |
| Body | Brass | Tri-alloy |
| Insulator | PTFE | --- |
| Center conductor | Phosphor bronze | Ag |
| Other | Brass | Tri-alloy |
