- Overview
- Recommended Products
- Series FME rf coaxial connector are thread coupling coaxial connectors.
- FME have the excellent performances of small size,easy connect/disconnect.
- Straight connectors are available for cable diameters from approximately 2.6mm to 5.5mm and also straight and right angle adapters other coaxial connectors series.
- Temperature range: -65 - +155°C
- Characteristic impedance: 50 ohms
- Frequency range:0-3GHz
-
Contact resistance:Working voltage: 500V (rms)
- Center conductor: ≤10m ohms
- Outer conductor: ≤5m ohms
- VSWR: ≤1.12
- Insulation resistance: ≥5,000M ohm
- Dielectric withstanding voltage: 1000V (rms)
- Durability: 500 times
Straight SMA Female to Female Jack RF Adapter Connector
RF pigtail cable jumper cable FME plug male to MMCX male for RG174 coaxial cable
Specifications
1.reasonable price
2.manufacturer factory
3.We are able to supply various types of connector according to clients’ requirement
4.Samples can be supplied for testing (for free)
5.Tried order is available
6.in stock
Available in various kinds of cable assemblies
Customized lengths are accepted
If you can not find the exact products you want in this page, please send enquiry to us, you will get an immediate reply within 1 hour at our working time, thanks for your visiting!~
Specifications
1.reasonable price
2.manufacturer factory
3.We are able to supply various types of connector according to clients’ requirement
4.Samples can be supplied for testing (for free)
5.Tried order is available
6.in stock
RF coaxial adapter brass material SMA female to SMB female connector
|
Temperature Range |
-55~+155°C (PE Cable -40~+85°C) |
|
|
Impedance |
50Ω |
|
|
Vibration |
98m/S2 (10~2000Hz), 10g |
|
|
Frequency Range |
DC-12.4GHz(semi-rigid cable DC-18 GHz) |
|
|
Insertion Loss |
<= 0.15dB/6GHz |
|
|
Withstanding Voltage |
1000V r.m.s at sea level |
|
|
Working Voltage |
335Vr.m.s at sea level |
|
|
Insulation Resistance |
>= 5000 MΩ |
|
|
Durability |
>= 500(cycles) |
|
|
Contact resistance: |
CenterContact <= 3mΩ |
|
|
Outer Contact <= 2.5mΩ |
||
|
Voltage Standing Wave Ratio: |
Straight |
flex cable <= 1.10+0.02f |
|
Semi-rigid cable <= 1.07+0.018f |
||
|
Right angle |
flex cable <= 1.20+0.03f |
|
|
Semi-rigid cable <= 1.17+0.02f |
||
