SMA jack female 2-holes flange mount connector 88 rf connector

Spu:

60218722386

Overview
Recommended Products

Specifications

SMA jack female 2-holes flange mount connector 88 rf connector

1.reasonable price

2.manufacturer factory

3.We are able to supply various types of connector according to clients’ requirement

4.Samples can be supplied for testing (for free)

5.Tried order is available

6.in stock

If you can not find the exact products you want in this page, please send enquiry to us, you will get an immediate reply within 1 hour at our working time, thanks for your visiting!~

Technical Characteristics

Temperature Range	-55~+155°C (PE Cable -40~+85°C)
Impedance	50Ω
Vibration	98m/S²(10~2000Hz), 10g
Frequency Range	DC-12.4GHz(semi-rigid cable DC-18 GHz)
Insertion Loss	<= 0.15dB/6GHz
Withstanding Voltage	1000V r.m.s at sea level
Working Voltage	335Vr.m.s at sea level
Insulation Resistance	>= 5000 MΩ
Durability	>= 500(cycles)
Contact resistance:	CenterContact <= 3mΩ
	Outer Contact <= 2.5mΩ
Voltage Standing Wave Ratio:	Straight	flex cable <= 1.10+0.02f
		Semi-rigid cable <= 1.07+0.018f
	Right angle	flex cable <= 1.20+0.03f
		Semi-rigid cable <= 1.17+0.02f
