14 Input Ports 2 Output Ports Poinit of Interface (POI) with PTFE Insulation Material

14 Input Ports 2 Output Ports Poinit of Interface (POI) with PTFE Insulation Material

14-Input 2-Output POI (PTFE Insulated): Multi-Operator RF Interface for 4G/5G Indoor/Outdoor Coverage

Overview
FAQ
Recommended Products

14 Input Ports 2 Output Ports Poinit of Interface (POI) with PTFE Insulation Material

Multi-Operator & Multi-Band Support: Integrates 14 input ports (covering 700MHz-3500MHz bands) for 5 operators (Maxis, Celcom, Digi, U Mobile, DNB/YTL) – unifies 4G/LTE/5G signals in one device
High Isolation & Low Loss: Same-band input isolation ≥30dB (minimizes cross-operator interference) + insertion loss ≤6.0dB (preserves signal strength)
Durable & Versatile: IP66 ingress protection (indoor/outdoor use) + -40°C~+85°C operating range – suits harsh deployment environments
Precise Signal Management: 30±3dB monitor port coupling + VSWR ≤1.3 – enables easy signal monitoring and optimization
High-Power Capacity: 43dBm per-port input power + ≤-150dBc intermodulation – handles high-density telecom signals

Operators	Band	Technology	Uplink(MHz)	Downlink(MHz)
Maxis	1800	GSM/LTE	1710-1730	1805-1825
	2100	LTE	1935-1950	2125-2140
	2600	LTE	2500-2520	2620-2640
Celcom	1800	GSM/LTE	1745-1765	1840-1860
	2100	LTE	1950-1965	2140-2145
	2600	LTE	2530-2550	2650-2670
Digi	1800	GSM/LTE	1765-1785	1860-1880
	2100	LTE	1965-1980	2155-2170
	2600	LTE	2550-2570	2670-2690
U Mobile	2100	LTE	1920-1935	2110-2125
	2600	LTE	2520-2530	2640-2650
DNB	700	LTE	703-743	758-798
	3500	5G (TDD)	3400-3500
YTL	2300	LTE (TDD)	2330-2360
Insertion Loss (dB)	≤6.0
Isolation BetweenInput Ports of (dB)	Same Bands ≥30
Monitor Port Coupling Value (dB)	Different Bands ≥90
Return Loss / VSWR	-40°C to +85 °C
Intermodulation (dBc)@2x43dBm	Indoor or outdoor (IP66)
Impedance (Ω)	5%-95%
InputPowerRatingPerPort (W)	30±3
Operation Temperature (°C)	≥ 18dB / ≤ 1.3
Degree of Protection	≤ -150

Indoor Distributed Antenna Systems (DAS): Unify 5 operators’ 4G/5G signals in malls, stadiums, or office buildings for seamless coverage
Outdoor Telecom Infrastructure: IP66-rated unit for multi-operator signal aggregation in base stations or tower-mounted setups
Public Venue Coverage: Support concurrent 4G/5G connectivity for large crowds (e.g., airports, concert halls) via 2 output ports
Multi-Operator Network Sharing: Enable cost-efficient signal integration for telecom providers (Maxis, Celcom, etc.) in shared coverage areas
