N-Type Crimp Plug Male Right Angle RF connector for LMR400 RG8 RG213 RG214 cable
1.reasonable price
2.manufacturer factory
3.We are able to supply various types of connector according to clients’ requirement
4.Samples can be supplied for testing (for free)
5.Tried order is available
6.in stock
N series RF connectors are 50 ohm constant impedance connectors with a consistently low VSWR across its frequency range of 0 to 11GHz. They are high quality medium size connectors standardly used with coaxial cables from .350" to .450" OD, but designs can also acccomodate .078" to .875" cables. N type connectors are threaded and gasketed for weatherproof operation. The threaded coupling incurs low noise and withstands shock and vibration. LTI N connectors are designed to conform to MIL-C-39012 specifications.
Offers a few styles of 75 ohm impedance versions of N connectors. They are not matable with the 50 ohm connectors.
The N series connector is the most popular medium sized connector. Applications include test and measurement, antennae, base stations, transmitters, etc.
| Product Series: | N |
| Product Type: |
Cable mount |
| Application: | Crimp |
| Body Plating: | Nickel-plated |
| Body Termination: | Crimp |
| Cable Type: | RG8,RG213,LMR400 |
| Connector Body Style: |
Right Angle |
| Connector Material: | Brass |
| Contact Plating: | Nickel |
| Contact Termination: | Solder |
| Gender: | Plug |
| Impedance: | 50 Ohm |
