PL259 UHF Male to PL259 UHF Male Rf Uhf Adapter Connector
- Overview
- FAQ
- Recommended Products
-
Broad Environmental Resilience
- Functions reliably in extreme temperatures (-55~+155°C; -40~+85°C with PE cable), ideal for harsh operating environments
-
Superior High-Frequency Performance
- Covers DC-6GHz frequency range; VSWR ≤1.15 (DC-3000MHz) and insert loss ≤0.15dB (6GHz) ensure low-distortion signal transmission
-
Strong Electrical Safety & Reliability
- High dielectric withstand voltage (≥1000V RMS) and insulation resistance (≥5000MΩ) prevent interference and ensure safe operation
-
Durable Low-Resistance Contacts
- Supports ≥500 mating cycles; center contact resistance ≤2.5mΩ and outer contact resistance ≤3mΩ for long-term stable conductivity
-
Secure & Stable Connection
- Interface retention force ≥60N avoids accidental disconnection during use
- RF Equipment Connection (e.g., radio transceivers, base station signal extension)
- Test & Measurement Setups (connecting signal generators, spectrum analyzers)
- Industrial & Aerospace Electronics (high-frequency signal transmission in harsh environments)
- Amateur Radio Systems (extending or adapting UHF signal lines)
PL259 UHF Male to PL259 UHF Male Rf Uhf Adapter Connector
Temperature Range |
-55~+155°C (PE Cable -40~+85°C) |
Impedance |
50Ω |
Frequency Range |
DC-6GHz |
VSWR |
≤ 1.15DC-3000MHz |
Insert Loss |
≤ 0.15dB (6GHz) |
Dielectric Withstanding Voltage |
≥1000V RMS,50Hz,at sea level |
Working Voltage |
≤ 480V |
Insulation Resistance |
≥ 5000 MΩ |
Durability |
|
Contact resistance: |
CenterContact ≤2.5mΩ |
Outer Contact ≤ 3mΩ | |
Interface retention force: |
≥60N |
FAQ
Q:what's your company MOQ?
A: In generally, if use customer brand, we will ask at least 500~800pcs, this we can negotiate.
Q: What's your delivery time?
A: This please ask our stock in first, products can send out once receive your deposit. If use customer brands, we will take a 3-5days to prepare materials and mass production.
Q: Can your company accept customize?
A: Welcome OEM & ODM.
Q: Can you send a sample for us to develop?
A: Yes, we can. Sample can send out once you ask for it, but will ask a sample fee. Sample fee will return back in future order
Q: Can you guarantee the quality of product?
A: Sure, high quality give us confidence to do business with your company. Long-term cooperation is what we need most instead of short-term cooperation.
Q: How do you solve after sale service?
A: This please ask us for technical support if you have workers know how to repair. If do not have engineers, please send back the items, we can repair the items for you.
Q:How do your company deal with the problem on quality ?
A: We have 20 years experience in this business. High quality and perfect service earn us great reputation. We will have a
detailed analysis of the problem. If our product is unqualified, we will deal with the problem according to contract. You have no need to worry about following problem. Our team will provide you great service.
