MCX R/A Solder Plug for .141 Semi-Rigid, 50 Ohm MCX RG402
1.reasonable price
2.manufacturer factory
3.We are able to supply various types of connector according to clients’ requirement
4.Samples can be supplied for testing (for free)
5.Tried order is available
6.in stock
Product Description
MCX Right Angle Solder Plug for .141 Semi-Rigid, 50 Ohm
Product Specifications
| Gender | Plug |
|---|---|
| Orientation | Right Angle |
| Cable Group | 10 |
| Insulator Material | PTFE |
| Body Material | Brass |
| Body Finish | Gold |
| Contact Material | Brass |
| Contact Finish | Gold |
| Termination Style | Cable - Solder |
| Impedance | 50 Ohm |
| Contact Termination | Solder |
| Coupling Mechanism | Push-on |
| Polarity | Standard |
| Max Freq (Ghz) | 6.0 |
| Ext Dielectric | No |
| Isolated | No |
| Low PIM | No |
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
