Packaging & Shipping
500 Piece In one Standard Export Carton
Product Description
SMA Connector Male Crimp For LMR400Cable
| Model No. | SMA-C-J400 | Interface | IEC 60169-15;CECC 22110;MIL-C-39012 | Electrical | Characteristic Impedance | 50ohm | Frequency Range | DC-12.4GHz | VSWR | ≤1.20@DC-3000MHz ; ≤1.35@3000MHz-6000MHz | Insertion Losss | ≤0.15dB/6GHz | 3rd Order IM (PIM3) | — | Working Vlotage | 335V RMS,50Hz,at sea level | Dielectric Withstanding Voltage | ≥1000V RMS,50Hz,at sea level | Dielectric Resistance | ≥5000MΩ | Contact Resistance | Center Contact ≤3mΩ | Outer Contact ≤2.5 mΩ | Mating | — | Mechanical | Durability | Mating cycles ≥500 | Material and Plating | Parts Name | Material | Plating | Body | Brass | Ni(Nickel) | Insulator | PTFE | — | Inner Conductor | Phosphor Bronze | Au(Gold) | Coupling Nut | Brass | Ni(Nickel) | Gasket | Silicone Rubber | — | Cable Clamp | — | — | Ferrule | Annealed Copper | Ni | Environmental | Operating Temperature | _45 °C~-85 °C | Weatherproof Rate | IP67 | RoHs (2002/95/EC) | Compliant by exemption | Suitable Cable Family | LMR400/RG213/RG8 Cable | ||||||||||||||||||||||||
