SMA female R/A connector right angle pcb mount waterproof
1.reasonable price
2.manufacturer factory
3.We are able to supply various types of connector according to clients’ requirement
4.Samples can be supplied for testing (for free)
5.Tried order is available
6.in stock
If you can not find the exact products you want in this page, please send enquiry to us, you will get an immediate reply within 1 hour at our working time, thanks for your visiting!~
Key Performance
|
Temperature range |
-65~+165 |
Insulation resistance |
≥5000MΩ |
||
|
Characteristic impedancd |
50Ω |
Working Voltage |
500V(rms) |
||
|
Frequency range |
With flexible cable |
0~12GHz |
Contact resistance |
Center conductor |
≤6mΩ |
|
With semi-rigid/flexible cable |
0~18GHz |
Outer conductor |
≤2mΩ |
||
|
VSWR |
Straight |
≤1.3 |
Durability(mating) |
500 Cycles |
|
|
Right Angle |
≤1.5 |
||||
|
Material And Plating |
|||||
|
Body |
Brass , nickel or gold plated |
||||
|
Center contacts |
Brass , gold plated |
||||
|
Insulators |
PTFE |
||||
|
Gaskets |
Silicon rubber |
||||
