N female to SMA female adapter N to SMA connector
Specifications
1.reasonable price
2.manufacturer factory
3.We are able to supply various types of connector according to clients’ requirement
4.Samples can be supplied for testing (for free)
5.Tried order is available
6.in stock
Product Description
N female to SMA female adapter N to SMA connector
| Electrical | |
| Impedance | 50 Ω |
| Frequency Range | 0 - 11 GHz |
| Voltage Rating | 1,500 volts peak |
| VSWR |
MIL-C-39012 straight connectors: 1.3 max 0-11 GHz MIL-C-39012 right angle connectors: 1.35 max 0-11 GHz |
| Dielectric Withstanding Voltage | 2,500 volts rms |
| Insulation Resistance | 5,000 MΩ minimum |
| Center Contact Resistance | 1.0 mΩ |
| Outer Contact Resistance | 0.2 mΩ |
| RF Leakage | -90 dB minimum at 3 GHz |
| Insertion Loss | .15 dB maximum at 10 GHz |
| Mechanical | |
| Mating | 5/8-24 threaded coupling |
| Braid or Jacket Cable Affixment |
All crimps: hex braid crimp Clamps: screw-thread nut and braid clamp |
| Center Conductor Cable Affixment |
Crimp: crimp or solder All others: solder only |
| Captivated Contact | All crimps unless specified otherwise |
| Cable Retention |
Crimps: 60-120 lbs Clamps: 30-70 lbs |
| Material | |
| Male Contacts | Brass, silver or gold plated |
| Female Contacts | Phosphorous bronze or beryllium copper, silver or gold plated |
| Other Metal Parts | Brass with ASTROplate® finish; M39012 has silver finish |
| Insulators | TFE, copolymer of styrene or glass-TFE (hermetic seal) |
| Weatherproof Gaskets | Silicone rubber of synthetic rubber |
| Crimp Ferrule | Copper |
| Environmental | |
| Temperature Range | TFE: -65°C to +165°C |
| Weatherproof | All series N with gaskets are weatherproof |
| Hermetic Seals | Pass helium leak test of 2x10-8 cc/sec |
| Pressurized Shock | Compression seal MIL-STD-202, method 213 |
| Vibration | MIL-STD-202, method 204, test condition B |
| Moisture Resistance | MIL-STD-202, method 106 |
| Corrosion | MIL-STD-202, method 101, test condition B |
| Temperature Cycling | MIL-STD-202, method 102, test condition C |
| Altitude | MIL-STD-202, method 105, test condition C |
| Military | |
|
MIL-C-39012 MIL-A-55339 |
Where applicable |
