RF adaptor n female to rp-sma female adapter
1.reasonable price
2.manufacturer factory
3.We are able to supply various types of connector according to clients’ requirement
4.Samples can be supplied for testing (for free)
5.Tried order is available
6.in stocK
RF adaptor n female to rp-sma female adapter
|
Major Technical Characteristics |
|||
|
Impedance |
50Ω
|
||
|
Frequency Range |
DC~11GHz |
||
|
Center conductor retention force |
≥0.56N |
||
|
Insertion Loss |
0.24dB(6GHz) |
||
|
Voltage Standing Wave Ratio |
Straight ≤1.15/6GHz |
||
|
Right angle ≤1.25/6GHz |
|||
|
Durability(mating) |
≥500(cycles) |
||
|
Material & Plating |
|||
|
Body |
Brass |
Nickel plated |
|
|
Pin contact |
Brass |
Gold plated |
|
|
Resilient contact |
Beryllium-copper |
Gold plated |
|
|
Socket contact |
Beryllium or tin bronze |
Gold plated |
|
|
Insulator |
PTFE |
||
|
Crimp ferrule |
Copper alloy |
Nickel or gold plated |
|
|
O-ring sealing |
6146 silicone rubber |
||
