sma male electrical clamp coaxial connector for rg58 rg223 cable
1.reasonable price
2.manufacturer factory
3.We are able to supply various types of connector according to clients’ requirement
4.Samples can be supplied for testing (for free)
5.Tried order is available
6.in stock
sma male electrical clamp coaxial connector for rg58 rg223 cable
|
Key Performance |
|||||
|
Temperature range |
-65~+165 |
Insulation resistance |
≥5000MΩ |
||
|
Characteristic impedance |
50Ω |
Dielectric Withstanding voltage |
1000V(r ms) |
||
|
Frequency range |
With flexible cable |
0~12.4GHz |
Contact resistance |
Center conductor |
≤3mΩ |
|
With semi-rigid/flexible cable |
0~18GHz |
Outer conductor |
≤2mΩ |
||
|
VSWR |
With flexible cable |
≤1.15+0.02F |
Durability |
500 Cycles |
|
|
With semi-rigid/flexible cable |
≤1.05+0.02F |
||||
|
Material And Plating |
|||||
|
Body |
Brass , gold plated or stainless steel passivated |
||||
|
Male center contacts |
Brass , gold plated |
||||
|
Female center contacts |
Beryllium copper , gold plated |
||||
|
Insulators |
PTFE |
||||
|
Gaskets |
Silicon rubber |
||||
|
Crimp ferrules |
Copper alloy , gold or nickel plated |
||||
