Mcx Female to Sma Male Adapter Mcx to Sma Connector Adaptor

Spu:
60246650829
  • Overview
  • Recommended Products

mcx female to sma male adapter mcx to sma connector adaptor



Product Description





Temperature Range

-55~+155°C (PE Cable -40~+85°C)

Impedance

50Ω, 75Ω

Frequency Range

DC-4GHz

Insertion Loss

less than or equal to 0.24dB/6GHz

Withstanding Voltage

1500V r.m.s   at sea level

Working Voltage

500Vr.m.s   at sea level

Insulation Resistance

>= 5000 MΩ

Durability

>= 500(cycles)

Contact resistance:

CenterContact   <= 1.5mΩ

Outer Contact   <=  1mΩ

Voltage Standing Wave Ratio:

Straight

<= 1.22/3GHz

Right angle

<= 1.30/3GHz
